V-tech Metalcraft

Brass Precision Turned parts

Description

We are manufacturing Brass CNC Turned Components at the highest quality precision. We offer highest standards and our services include CNC Machining, Milling, Drilling ,Turning, Lathe Work, Grinding, Routing Turned Parts and the manufacturing of precision turned components comprised of a wide range of materials. We can work with materials Brass, Copper, Aluminum and more.
V-tech Metalcraft provide wide range of precision brass CNC Turned Parts, CNC Precision Turned Components for HRC Fuse Connectors, links, instrumentation, electrical. telecommunication electronics, automotive and light engineering industries. CNC Turned Parts are manufactured using automatic and semiautomatic machines under high grande and accuracy.
Brass CNC Turned Parts as per the DIN, ISO, Metric, UN standard or as per customer's specification. Further, the serval quality check is carried out by our professionals for confirmation and thereafter forwarded for the export packing. We have the ability to machine simple to complex brass parts with accurate size/tolerance ± 0.02 to 0.00 in any volume.



Material :

» High Grade Free Cutting Brass
» Brass Alloy: CuZn39Pb3 / CuZn39Pb2 / CuZn38Pb1.5 / CuZn37Pb2 / CuZn40Pb2 / MS 58 / BS2874 / IS 319 (Type I & II)
» UNS (ASTM): C35300 / C35330 DZR / C36000 (CDA 360) / C36500 / C37000 / C37100 / C37700 / C37710 / C38500
» BS: CZ121 / CZ122 / CZ124 / CZ128 / CZ 131 / CZ132
» EN: CW602N / CW603N / CW606N / CW608N / CW612N / CW614N / CW617N
» JIS: C3601 / C3602 / C3603 / C3604 / C3605 / C3712 / C3771

Any special brass material compositions as per customer’s requirement





Threads :

» ISO Metric (MM) / BA / BSW / BSP / BSPT / BSF / BSB / UNC / UNF / UNEF / NPT / NPS / Specified Threads Any threads as per client specification





Features :

» Ideal for highly customized Precision components.
» Provides high quality surface finish.
» Complex parts can be made effectively.
» Accuracy of 10 to 20 microns can be achieved with high precision.





Finish :

Natural Clean / Nickel Plated / Electro-Tin Plated / Silver Plated / Copper Plated / Zinc Plated / Chrome Plated / Specified Surface Finish.





Any Type of Brass CNC Turned Components can be developed and supplied exactly as per customer specifications or drawing
